12v Plastic ac to dc dc regulated power supply 12v regulated

12v Plastic ac to dc dc regulated power supply 12v regulated

  • 12v Plastic ac to dc dc regulated power supply 12v regulated
12v Plastic ac to dc dc regulated power supply 12v regulated
Product Details:
Place of Origin: China
Brand Name: HIC
Certification: ISO
Output Power: 301 - 400W
Output Type: Dual
Input Voltage: 100~240
Output Voltage: Adjustable
Output Frequency: 50~60HZ
Output Current: 2A /1a
Material: Plastic / Metal
Delivery Method: EMS/DHL/UPS/TNT/FEDEX
MTBF: More than 100,000hours
Payment Method: L/C/T/T ,Western Union /MoneyGram
Color: Block / White
DC Tip: Oval tip
AC Type: US/UK/AU/EU/CH etc.
Model Label: Customize
Certificate: CCC,FCC,ROHS,UL,GS
Efficiency: More than 88%
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: According to customer’s requirment
Delivery Time: 7-15days
Payment Terms: L/C T/T,Paypal
Supply Ability: 500,000 Piece/Pieces per Month and more
Contact Now
Detailed Product Description
High Light:

Switch Power Supply

,

Computer Switching Power Supply


1:Product name :12v regulated power supply
2:Input :100v ~240v
3:Output : 5w~120w
4:Material :Plastic

US ac to dc power adapter 12v regulated power supply

Model: winwell-12G-12 FUK
Max output wattage: 12W
AC input voltage: 100V-240V (90-264Vac max)
AC frequency: 47-63Hz
DC output: 12V (output regulation 11.3V-14.5V)
DC output: 0 to 1A max
No load power consumption: <;;0.3W
Efficiency: 78% minimum
Ripple and noise: 400MVP-p
Working temperature: 0-40 degrees Max
Leakage current: <;;0.25mA
Short circuit protection
Over current protection
Over voltage protection
Open circuit protection

US ac to dc power adapter 12v regulated power supply


Humidity:
Operating humidity: 20 to 85% RH
Storage humidity: 5 to 95% RH
Hi-pot test:
Hi-pot: 3, 000V AC (primary-secondary)
MTBF (mean time between failures): 50, 000 hours at 25 degrees Centigrade
Dimensions: 70 x 49.2 x 72.7mm (L x W x H) maximum
Safety: TUV- BS, CE
Safety standard: EN 60950-1
Meet CEC: Level V
