Single Output Mode Switch 25W 24V dc regulated power supply

Single Output Mode Switch 25W 24V dc regulated power supply

  • Single Output Mode Switch 25W 24V  dc regulated power supply
Single Output Mode Switch 25W 24V  dc regulated power supply
Product Details:
Place of Origin: China
Brand Name: HIC
Certification: ISO
Output Power: 1 - 50W
Output Type: Single
Input Voltage: 85-132/170-264VAC selected by switch; 240-370VDC
Output Voltage: 5V-24V
Output Frequency: 47-63Hz
Output Current: 0-5A
Input Current: 0.7A/115V 0.3A/230V
AC Inrush Current: Cold-Start Current: 15A/115V, 30A/230V
Overload Protection: 105%~150% Type: Foldback Current Limiting, Reset: Auto Recovery
Start, Rise, Hold time: 800ms, 50ms, 30ms,/ 115VAC, 300ms, 50ms, 80ms, /230VAC
Dimension: 99*97*35mm
Weight: 0.3kgs
Certificates: ISO 9001:2000; CE
Warranty: 2 years
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: According to customer’s requirment
Delivery Time: 7-15days
Payment Terms: L/C T/T,Paypal
Supply Ability: 50000 Piece/Pieces per Month more
Contact Now
Detailed Product Description
High Light:

Computer Switching Power Supply

,

Computer Switching Power Supply


1. We have 5 Years Export Experience
2. 100% full load burn-in test
3. Approved CE, ISO 9001 certificates
4. 2 years warranty

SWITCH POWER SUPPLY SINGLE TYPE S SERIES S-25W

1. Features

1. Low price and high reliable.

2. 105 `C output capacitor

3. AC input power suitable for the world

4. High efficiency and how operation temperature.

5. Soft-start current can reduce the AC input impact effecticly.

6. With short-circuit and overload protection.

7. Compact size, light weight.

8. 100% full-load buming test.

9. installed with EMI filter, minmum wave.

10. S-25-24 Single Output Mode Switch DC Regulated 25W 24V Power Supply S-25-24

2.Specification

Model SpecificationS-25-5VS-25-12VS-25-15VS-25-24V
DC Output Voltage5V12V15V24V
Iutput Voltage Error± 2%± 1%± 1%± 1%
Rated Output Current5A2.1A1.7A1.1A
Output Current Range0-5A0-2.1A0-1.7A0-1.1A
Tripple and Noise75mVp-p100mVp-p100mVp-p100mVp-p
Iniet Stability± 0.5%± 0.5%± 0.5%± 0.5%
Tolerance Voltage± 1%± 0.5%± 0.5%± 0.5%
DC Output Power25W25.5W25.5W26.4W
Efficiency72%76%77%80%
Adjustable Range for DC Voltage`+10, -5%± 10%± 10%± 10%
AC Input Voltage Range85~132VAC/170~264VAC selected by switch 47~63Hz; 240~370VDC
Input Current0.7A/115V 0.3A/230V
AC Inrush CurrentCold-Start Current: 15A/115V, 30A/230V
Leakage Current<;;0.75mA/240VAC
Overload Protection105%~150% Type: Foldback Current Limiting, Reset: Auto Recovery
Over Voltage Protection…………
High Temperature Protection…………
Temperature Coefficient± 0.03% /°C (0~50°C)
Start, Rise, Hold time800ms, 50ms, 30ms,/ 115VAC, 300ms, 50ms, 80ms, /230VAC
Vibration10~500Hz, 2G 10min,/1cycle, a total of 60 minutes, Each axes
Withstand VoltageBetween Input and Output: 1.5KVAC, Input and Shell: 1.5KVAC, Output and Shell: 0.5KVAC
Isolation ResistanceInput and Output Intermal: Input and Enclosute, Output and Enclosure: 500VDC/100M Ohms
Working Temperature and Humidity`-10°C~+60°C (Refer to Output Derating Cutve), 20%~90%RH
Storage Temperature and Humidity`20°C~+85°C, 10%~95%RH
Overall Dimension99*97*35mm
Weight0.3kgs
Safety StandardsMeet UL 1012 requirement (Not apply for the mark)
EMC StandardsMeet FCC Part 15J Conduction class B

3. Mechanical Dimension:

4. Certificates:

5. Please Note:

1. The testing condition for the parameter above is: 230VAC input, rated load, 25°C 70%Rh, Humidity.

2. Error, include the setting error, line stability and load stability.

3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting.

4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage.

5. Load stability test: the load is from 0% to 100%, others 60%.

6. C6 must be knocked down.
