| Place of Origin: | China |
| Brand Name: | HIC |
| Certification: | ISO |
| Output Power: | 51 - 100W |
|---|---|
| Output Type: | Single |
| Input Voltage: | 85-264VAC; 120-370VDC |
| Output Voltage: | 3.3V-48V |
| Output Frequency: | 47-63Hz |
| Output Current: | 0-20A |
| Over load protection: | 105%-150% constant current, auto-recovery. |
| Over voltage protection: | 110%-135% rated output voltage |
| Dimension (L*W*H): | 179*99*45 mm |
| Certificates: | ISO 9001:2000 |
| Warranty: | 2 years |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | According to customer’s requirment |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C T/T,Paypal |
| Supply Ability: | 50000 Piece/Pieces per Month |
| High Light: | Switching Power Supply,Switching Power Adapter |
||
|---|---|---|---|
SWITCH POWER SUPPLY SINGLE TYPE SP SERIES SP-100W
1. Features
1. Universal AC input/ full range
2. PF>0.93@115VAC; >0.93@230VAC
3. Protections: short circuit, overload, over-voltage, over temp.
4. Built-in constant current limiting circuit
5. Remote ON/OFF control (option)
6. Approvals: UL/CUL/TUV/CB/CE/S-MARK
7. Cooling by free air convection
8. 2 years warranty
9. SP-100-3.3 Industrial Single Output AC DC SMPS Switch 3.3V DC Led Power Supply
2.Specification
| Model | Output | Tolerance Voltage | Ripple and Noise | Efficiency |
| SP-100-3.3 | 3.3V, 0-20A | ± 2% | 100mvp-p | 70% |
| SP-100-5 | 5V, 0-20A | ± 2% | 100mvp-p | 76% |
| SP-100-7.5 | 7.5V, 0-13.5A | ± 2% | 100mvp-p | 78% |
| SP-100-12 | 12V, 0-8.5A | ± 2% | 100mvp-p | 80% |
| SP-100-13.5 | 13.5V, 0-7.5A | ± 2% | 100mvp-p | 80% |
| SP-100-15 | 15V, 0-6.7A | ± 2% | 100mvp-p | 82% |
| SP-100-24 | 24V, 0-4.2A | ± 1% | 150mvp-p | 84% |
| SP-100-27 | 27V, 0-3.8A | ± 1% | 150mvp-p | 83% |
| SP-100-48 | 48V, 0-2.1A | ± 1% | 200mvp-p | 82% |
1. AC input voltage range: 85-264VAC; 120-370VDC
2. DC adjustment range: -5-+10% rated output voltage.
3. Over load protection: 105%-150% constant current, auto-recovery.
4. Over voltage protection: 110%-135% rated output voltage.
5. Withstand voltage: I/P-O/P:3KVAC,I/P-FG:1.5KVAC,1minute
6. Working temperature: -10-+50°C (refer to the derating curve)
7. ENC standards: EN 55022 class B, EN61000-3-2,3,EN6100-4,2,3,4,5,6,8,11,EN50204
8. Connection: 7P/9.5 mm pitch terminl block with cover
9. Dimension (L*W*H): 179*99*45 mm
3. Mechanical Dimension:
4. Certificates:
5. Please Note:
1. The testing condition for the parameter above is: 230VAC input, rated load, 25°C 70%Rh, Humidity.
2. Error, include the setting error, line stability and load stability.
3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting.
4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage.
5. Load stability test: the load is from 0% to 100%, others 60%.
6. Total output canbe maximum Current, total load can not exceed the maximum output power.
