| Place of Origin: | China |
| Brand Name: | HIC |
| Certification: | ISO |
| Output Power: | >500W |
|---|---|
| Output Type: | Single |
| Input Voltage: | 90-130/180-260VAC |
| Output Voltage: | 12V-48V |
| Output Frequency: | 47-63Hz |
| Output Current: | 0-80A |
| AC inrush current: | cold start, 60A at 230VAC |
| Setup, rise, hold up time: | 800ms,50ms,16ms at full load and 230VAC |
| Overload protection: | 110-135% constant current limiting, delay shutdown |
| Over voltage protection: | 110-135% rated output voltage |
| Dimension (L*W*H): | 291*120*68 mm |
| Certificates: | ISO 9001:2000 |
| Warranty: | 2 years |
| Minimum Order Quantity: | Negotiation |
|---|---|
| Price: | Negotiation |
| Packaging Details: | According to customer’s requirment |
| Delivery Time: | 7-15days |
| Payment Terms: | L/C T/T,Paypal |
| Supply Ability: | 50000 Piece/Pieces per Month more |
| High Light: | Switching Power Supply,universal power ac adapter |
||
|---|---|---|---|
SWITCH POWER SUPPLY SINGLE TYPE SCN SERIES SCN-1000
1. Features
1. AC input range selectable by switch
2. Protections: short circuit/ over voltage/ overload/ over temp.
3. Built-in remote ON/OFF control
4. Built-in remote sense function
5. Built-in parellel operation function
6. Can adjust from 20-100% output voltage by external control 1-5VDC
7. Forced air cooling by built-in DC fan
8. 2 years warranty
9. SCN-1500-24 AC DC Industrial SMPS Led Driver Switch 24 Volt 1500W Power Supply
2.Specification
| Model | Output | Tolerance Voltage | Ripple and Noise | Efficiency |
| SCN-1000-12V | 12V, 0-80A | ± 1% | 240mvp-p | 84% |
| SCN-1000-13.5V | 13.5V,0-74A | ± 1% | 240mvp-p | 84% |
| SCN-1000-15V | 15V, 0-66A | ± 1% | 240mvp-p | 83% |
| SCN-1000-24V | 24V, 0-40A | ± 1% | 240mvp-p | 86% |
| SCN-1000-27V | 27V, 0-37A | ± 1% | 300mvp-p | 87% |
| SCN-1000-48V | 48V, 0-20A | ± 1% | 300mvp-p | 87% |
1. AC input voltage range: 90-130VAC/180-260VAC selectable by switch
2. AC inrush current: cold start, 60A at 230VAC
3. DC adjustment range: ±5% rated output voltage by potential meter 20-100% by external control voltage 1-5VDC
4. Setup, rise, hold up time: 800ms,50ms,16ms at full load and 230VAC
5. Overload protection: 110-135% constant current limiting, delay shutdown.
6. Over voltage protection: 110-135% rated output voltage
7. Withstand voltage: I/P-O/P, I/P-FG: 1500VAC, 1minute
8. Working temperature: -10°C~+50°C@100%, 65°C@50% load
9. Packing Size: 2.6kg, 6pcs/15.6kg/CTN
10. Dimension (L*W*H): 291*120*68 mm
3.Certificates:
4. Please Note
1. The testing condition for the parameter above is: 230VAC input, rated load, 25°C 70%Rh, Humidity.
2. Error, include the setting error, line stability and load stability.
3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting.
4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage.
5. Load stability test: the load is from 0% to 100%, others 60%.
6. Total stability test: the load is from 0% to 100%, others 60%.
7. C2,3,6 must be knocked down.
