| Place of Origin: | Shenzhen,China |
| Brand Name: | RAYTOP |
| Certification: | CE, RoHS, FCC |
| Model Number: | ETU050200-1-1 |
| Minimum Order Quantity: | 1000 Pieces |
|---|---|
| Price: | Negotiable |
| Packaging Details: | PE Bag/ Color Box/White Box, Master Carton |
| Delivery Time: | 15-20 work days. |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 500,000 Pcs |
| Application: | Tablet | Approval: | CE, RoHS, FCC, UL |
|---|---|---|---|
| EMI Standards: | FCC Part 15 Class B | Feature: | Constant Voltage |
| Frequency: | 50Hz / 60Hz | Input: | AC100-240V |
| MTBF: | 50000 Hours | Operating Temperature: | 0~40℃ |
| Output: | 5V 2000mA | Output Power: | 10W |
| Plug: | EU, US, UK, SAA, CCC | Product Name: | Mini Usb Car Charger |
| Protection: | SCP, OVP, OCP | ||
| High Light: | portable universal usb charger,portable usb travel charger |
||
Quick Detail:
-Input Voltage: AC100-240V, 50/60Hz;
-Output Voltage& Current : USB 5V, 2.0A;
-Efficiency: ≥80%;
-Operating temperature: 0 ~ 40°C;
-Storage temperature: - 20°C to 70°C;
-Protection: SCP/OVP/OCP;
-Cable and different connectors configuration for choice.
-Plug: EU, UK, US,CCC,SAA etc.
-CE and RoHS certified.
-2 Year Warranty.
Description:
USB power adapter, 5V, 2.0A, small size, used for iPhone, mobile phones, PDA, GPS, Sony's PSP, digital cameras etc.
Applications:
Compatible with Mobile Phone/iPad/PSP/ Ipod/Iphone/
GPS/Camera/MP3/MP4/PDA etc.
Specifications:
|
Input |
Rated Input Voltage |
AC100~240V |
|
Input Voltage Range |
AC 90~264V |
|
|
Rated Frequency |
50/60 Hz |
|
|
Input Frequency Range |
47~63 Hz |
|
|
Input AC Current |
500mA |
|
|
Inrush Current |
30A |
|
|
Output |
Rated Output Voltage |
DC5V |
|
Output Voltage |
DC5V+/-0.5V |
|
|
Rated Output Current |
2.0A |
|
|
Rated Power |
Max.10W |
|
|
Ripple and Noise |
150mV p-p |
|
|
Standby Power Consumption |
0.3W |
|
|
Turn-on |
5s |
|
|
Hold-up |
20s |
|
|
Over Voltage Protection |
Yes |
|
|
Over Current Protection |
Yes |
|
|
Short Circuit Protection |
Yes, automatically recover after short circuit removed. |
|
|
Reliability |
Hi-pot |
3000Vac |
|
Insulation Resistance |
Input to output at 500Vdc |
|
|
Leakage Current |
5mA |
|
|
EMI Standards |
FCC Part 15B Class B |
|
|
RoHS Compliant |
Yes |
|
|
MTBF |
50,000 hours |
|
|
Burn-in |
40+/-5 ℃, full load, 12 hours |
|
|
Drop Test |
6 direction, each one time from height 1.0M |
|
|
Environmental |
Operating Temperature |
0~40℃ |
|
Operating Humidity |
10~80% |
|
|
Storage Temperature |
-20~65℃ |
|
|
Storage Humidity |
0~90% |
|
|
Safety Approvals |
CE, RoHS, FCC, UL, SAA |
|
|
Warranty |
2 Years |
|
Competitive Advantage:
-Open private model w/o extra cost for you;
-0.3% backup of order quantity freely;
-Direct factory price without middle man.
-High performance-to-price ratio;
-Perfect after-sale service.
