OEM ODM 4.5V 180W Car LED Power Supply with Low Ripple Noise

OEM ODM 4.5V 180W Car LED Power Supply with Low Ripple Noise

  • OEM ODM 4.5V 180W Car LED Power Supply with Low Ripple Noise
OEM ODM 4.5V 180W Car LED Power Supply with Low Ripple Noise
Product Details:
Place of Origin: China
Brand Name: G-ORIENT
Certification: ISO9001 / CE / ROHS / FCC
Model Number: NBD200-4.5-A
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: negotiable
Packaging Details: 20pcs/16Kgs / CARTONS
Delivery Time: 10 working days after received your payment
Payment Terms: T/T or Paypal
Supply Ability: 50,000pcs per month
Contact Now
Detailed Product Description
Application: On-board Screen, Taxi LED Sign Ripple & Noise: ≤250mVp-p
Standard: CE / ROHS / FCC High Efficiency: 91%
Operating Temperature: -30℃ ~ +60℃
High Light:

slim power supply

,

small power supply





OEM ODM 4.5V 180W Car LED Power Supply with Low Ripple Noise





Applications:

This power supply suitable for automobile,ship,electric cars,new energy products,LED electronic signs,car audio,and other energy-saving appliances stable power supply use.





Features:

* Low output ripple and noise

* 2 years warranty

*  Aluminum metal shell,natural cooling

*  Input reverse connect protection

* Through the EMC certification

* High efficiency 94% & small size

* To prevent car screen flower screen, the splash screen and two horizontal line design





Company Advantage:

* Professional R&D team

* High quality products

* Short lead time* Standardized production process





Competitive Advantage:

* Low output ripple and noise

* The two level output over voltage protection

* High efficiency up to 94%

* CE / ROHS / FCC approval

* Output over-current,short-circuit,over-load,over-voltage protection

* Ultra-thin 18mm





Specifications:

Switching power supply

 NBD200-4.5-A

 OUTPUT

DC Voltage

 4.5V

Current Range

 0~20A x 2

Rated Current

 40A (2 independent output)

Rated Power

 180W

Ripple & Noise(max.)

 <200mVp-p

Voltage set point accuracy

 +/- 3.0%Vo max

Over-current protection

 >120%io,hiccup

Line Regulation

 0.2%Vo max

Load Regulation

 0.2%Vo max

Short-circuit protection

 Hiccup

Hold up time

 >8mS

Overshoot and undershoot

 < +/- 5.0%

 INPUT

Voltage Range

 DC9-36V

Frequency Range

 BW=20MHz

Efficiency(Typ.)

 94%

DC Current

 <25A

Inrush Current(Typ.)

 100A at DC Cold start

Leakage Current

 Input-Output< 0.2mA ; Input-PG:<0.3mA

 Environment

MIBF

 >2 million hrs

Temp.Coefficient

 < 0.02%/℃

Storage Temperature range

 -55 ~ +115℃

Operaing board Temperature range

 -25 ~ +65℃

 Safety

Safety standards

 CE

Withstand Voltage

 DC40V

 Others

Dimension

 152*100*18mm (L*W*H)

Packing



 Note
