LED constant Voltage Driver
Product Details:
Place of Origin: Shenzhen,China
Brand Name: Sunshineopto
Certification: ROHS
Model Number: S-150W-12V
Payment & Shipping Terms:
Minimum Order Quantity: 100PCS
Price: Need to negotiate
Packaging Details: 50pcs per carton 53x24x43.2cm
Delivery Time: 3-4 WORK DAYS
Payment Terms: T/T,PAYPAL,Western Union,Money Gram
Supply Ability: 10000pcs for one week
Contact Now
Detailed Product Description
Voltage: 12v Constant Voltage Current: 12.5A
Power: 150W Switching Power Supply: Indoor Lights
Waterproof: No Warranty: 2 Years
High Light:

Led Light Power Supply

,

waterproof LED power supply

150W AC 110V / 220V 50HZ - 60Hz LED Power Supply 12V 12.5A LED constant Voltage





Quick Detail:



1 Model No.:  S-150-12

2 Appearance Dimension: 198(L)*98(W)*42(H)mm

3 N.W.: 0.8kg/pc

4 Canning Material: Aluminum

5 Input voltage :AC110V/220V 50-60Hz

6 Output voltage :12V ±2%DC

7 Output current : 12.5A±0.5%

8.Package dimension :53x24x43.2cm 50pcs/ctn 25.5kgs/ctn





Description:



1 Environmental Conditions

1.1 Operating Temperature: -10℃~+50℃, 20%~95%RH(without condensation)

1.2 Storage Temperature: -20℃~+85℃, 20%~95%RH(without condensation)

2.3 Relative Humidity: 0.02~0.05%/℃

3.4 Heat-dissipating Method: Natural Cooling / Fan Cooling / Blower Cooling

2. Input Features

2.1 Rated Input Voltage Range:220VAC

2.2 Input Voltage Range: 110/220VAC±15%

2.3 Input Frequency Range:50~60Hz(except Dc input)

2.4 Input Under-voltage Protection:115~150% interim mode

2.5 Input Under-voltage Recovery: Automatic recovery

2.6 Input Over-voltage Protection:115~150% interim mode

2.7 Input Over-voltage Recovery: Automatic recovery

2.8 Impact Current ≤1% (the highest input voltage full load)

2.9 Overall Efficiency ≤0.5% (rated input full load)

3. Output Features

3.1 Output Voltage Range: 12V±2%(Dual Outputs)

3.2 Output Current Range: 12.5A±0.5%(Dual Outputs)

3.3 Ripple & Noise(mVp-p)≤100 mVp-p

3.4 Rise Time≤50 ms

3.5 Output Delay≤S

3.6 Voltage Adjustment Rate≤0.5%

3.7 Load Adjustment Rate≤1%





Applications:



General Illumination

- Outdoor & Indoor architectural lighting

- Decorative lighting

- Flood lighting,cast light lamps

- Street lamp,Tunnel lamp

- Replace the old equipment





Specifications:



Product Name

150W LED power supply 12V constant voltage Indoor

Model No

S-150-12

 Material

Aluminum case

MOQ

50pcs

Size

198(L)*98(W)*42(H)mm

Package

G.W.:540g

Sample

3-5 work days

Delivery

7-10 work days

Certificate

ROHS

Quality guarantee

2 years warranty

 Main market

Europe, America, Asia





Shipping and delivery time:



DHL/UPS/TNT/FEDEX

4-5 working days

EMS

10-15 working days

HK Post Air Mail Register

15-18 working days

Trade Terms

FOB|EXW|CIF|CFR

Sample availability

YES

Delivery time

3-4 working days





Competitive Advantage:



1 .Output Over Current Protection: Current drooping type

2. Output Short Circuit Protection: IGBT

3. Output Over-voltage Protection: Soft start protection

4. Reliability Requirements

5 MTBF:50,000 HOURS

6 Annual Repair Rate<0.3%



Test & Package :

LED constant Voltage Driver 0
