12V-48V 1000W AC DC Industrial SMPS constant current led power supply

12V-48V 1000W AC DC Industrial SMPS constant current led power supply

  • 12V-48V 1000W AC DC Industrial SMPS constant current led power supply
12V-48V 1000W AC DC Industrial SMPS constant current led power supply
Product Details:
Place of Origin: China
Brand Name: HIC
Certification: ISO
Output Power: >500W
Output Type: Single
Input Voltage: 90-130/180-260VAC
Output Voltage: 12V-48V
Output Frequency: 47-63Hz
Output Current: 0-80A
AC inrush current: cold start, 60A at 230VAC
Setup, rise, hold up time: 800ms,50ms,16ms at full load and 230VAC
Overload protection: 110-135% constant current limiting, delay shutdown
Over voltage protection: 110-135% rated output voltage
Dimension (L*W*H): 291*120*68 mm
Certificates: ISO 9001:2000
Warranty: 2 years
Payment & Shipping Terms:
Minimum Order Quantity: Negotiation
Price: Negotiation
Packaging Details: According to customer’s requirment
Delivery Time: 7-15days
Payment Terms: L/C T/T,Paypal
Supply Ability: 50000 Piece/Pieces per Month more
Contact Now
Detailed Product Description
High Light:

Switching Power Supply

,

Switching Power Adapter


1. We have 5 Years Export Experience
2. 100% full load burn-in test
3. Approved CE, ISO 9001 certificates
4. 2 years warranty

SWITCH POWER SUPPLY SINGLE TYPE SCN SERIES SCN-1000

1. Features

1. AC input range selectable by switch

2. Protections: short circuit/ over voltage/ overload/ over temp.

3. Built-in remote ON/OFF control

4. Built-in remote sense function

5. Built-in parellel operation function

6. Can adjust from 20-100% output voltage by external control 1-5VDC

7. Forced air cooling by built-in DC fan

8. 2 years warranty

9. SCN-1000-24 AC DC Industrial SMPS Led Driver Switch 24 Volt Switching Power Supply 1000W

2.Specification

ModelOutputTolerance VoltageRipple and NoiseEfficiency
SCN-1000-12V12V, 0-80A± 1%240mvp-p84%
SCN-1000-13.5V13.5V,0-74A± 1%240mvp-p84%
SCN-1000-15V15V, 0-66A± 1%240mvp-p83%
SCN-1000-24V24V, 0-40A± 1%240mvp-p86%
SCN-1000-27V27V, 0-37A± 1%300mvp-p87%
SCN-1000-48V48V, 0-20A± 1%300mvp-p87%

1. AC input voltage range: 90-130VAC/180-260VAC selectable by switch

2. AC inrush current: cold start, 60A at 230VAC

3. DC adjustment range: ±5% rated output voltage by potential meter 20-100% by external control voltage 1-5VDC

4. Setup, rise, hold up time: 800ms,50ms,16ms at full load and 230VAC

5. Overload protection: 110-135% constant current limiting, delay shutdown.

6. Over voltage protection: 110-135% rated output voltage

7. Withstand voltage: I/P-O/P, I/P-FG: 1500VAC, 1minute

8. Working temperature: -10°C~+50°C@100%, 65°C@50% load

9. Packing Size: 2.6kg, 6pcs/15.6kg/CTN

10. Dimension (L*W*H): 291*120*68 mm

3.Certificates:

4. Please Note

1. The testing condition for the parameter above is: 230VAC input, rated load, 25°C 70%Rh, Humidity.

2. Error, include the setting error, line stability and load stability.

3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting.

4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage.

5. Load stability test: the load is from 0% to 100%, others 60%.

6. Total stability test: the load is from 0% to 100%, others 60%.

7. C2,3,6 must be knocked down.
