Switching Power Supply

SWITCH POWER SUPPLY SINGLE TYPE SCN SERIES SCN-1000

1. Features

1. AC input range selectable by switch

2. Protections: short circuit/ over voltage/ overload/ over temp.

3. Built-in remote ON/OFF control

4. Built-in remote sense function

5. Built-in parellel operation function

6. Can adjust from 20-100% output voltage by external control 1-5VDC

7. Forced air cooling by built-in DC fan

8. 2 years warranty

9. SCN-1000-27 Led Driver Switch Power Supply 1000W 27V 37A SMPS

2.Specification

1. AC input voltage range: 90-130VAC/180-260VAC selectable by switch

2. AC inrush current: cold start, 60A at 230VAC

3. DC adjustment range: ±5% rated output voltage by potential meter 20-100% by external control voltage 1-5VDC

4. Setup, rise, hold up time: 800ms,50ms,16ms at full load and 230VAC

5. Overload protection: 110-135% constant current limiting, delay shutdown.

6. Over voltage protection: 110-135% rated output voltage

7. Withstand voltage: I/P-O/P, I/P-FG: 1500VAC, 1minute

8. Working temperature: -10°C~+50°C@100%, 65°C@50% load

9. Packing Size: 2.6kg, 6pcs/15.6kg/CTN

10. Dimension (L*W*H): 291*120*68 mm

3.Certificates:

4. Please Note

1. The testing condition for the parameter above is: 230VAC input, rated load, 25°C 70%Rh, Humidity.

2. Error, include the setting error, line stability and load stability.

3. Wave test: adopting "A12" double wire for 20MHZ, and 0.1uF&uF capacitor short-circuit for interrupting.

4. Inlet Voltage Stability test: when is over load, the lowest voltage of inler is representative to the highest voltage.

5. Load stability test: the load is from 0% to 100%, others 60%.

6. Total stability test: the load is from 0% to 100%, others 60%.

7. C2,3,6 must be knocked down.
