Place of Origin: | China |
Brand Name: | HIC |
Certification: | ISO |
Model Number: | KSUFB |
FOB: | Shenzhen Hongkong |
---|
Minimum Order Quantity: | Negotiation |
---|---|
Price: | Negotiation |
Packaging Details: | According to customer’s requirment |
Delivery Time: | 7-15days |
Payment Terms: | L/C T/T,Paypal |
Highlight: | laptop universal power adapter |
---|
Key Features of KSUFB series
●Light, extra slim, sleek, compact design
●Green power, full complies with CEC level V, MEPS V EUP2011
●High power density
●Extra safe design, have got their respective safety approvals
●Completed protect function
Key Applications of KSUFB series
It’s suitable for an extremely wide range of applications, including:
●Mobile Devices
●Set-top-box
●ADSL
●Audio & Video product
●Household appliance
●Charger
●Input Voltage: 90 to 264 VAC
●Frequency : 47-50/60-63hz
●Input current : 0.15A(Max) 100 /240VAC
●Inrush current : 50 AMax. 100VAC at max. Load
60AMax.240VAC at max. Load
●Over voltage protection
●Over current protection
at 110-200% of lo and Auto-recovery
●Electronic short circuit protection
●Operatingtemperature 0~40℃Free convection
●Operating humidity 10-90% RH Non Condensing
●Sea level Non-operating temperature -20~80℃
●Information technology equipment
●IEC/EN 60950-1, UL 60950-1, CSA C22.2
No. 60950-1-03
IEC/EN 60065, UL 60065, GB4943, K60950
●CB , GS , CE , UL , CCC , FCC, C-TICK, PSE, KC
●Radiation Test&Conduction Test: EN 55022/FCC Part 15
●Harmonic Test:EN 61000-3-2
●Flicker Test:EN 61000-3-3
●ESD Test:EN 61000-4-2
●RS Test:EN 61000-4-3
●EFT Test:EN 61000-4-4
●Surge Test:EN 61000-4-5
●CS Test:EN 61000-4-6
●DIP Test:EN 61000-4-11
Dimension L*W*H (mm) :70 * 36 * 25.5
