Name: 5v regulated 12W Plug DC Adapter dc regulated power supply
Brand: Shenzhen Power Adapter Co.,Ltd.
Availability: InStock

Home Products Uninterrupted Power Supply

5v regulated 12W Plug DC Adapter dc regulated power supply

Product Details:

Place of Origin:	China
Brand Name:	HIC
Certification:	ISO
Output Power:	301 - 400W
Output Type:	Dual
Input Voltage:	100~240
Output Voltage:	Adjustable
Output Frequency:	50~60HZ
Output Current:	2A /1a
Material:	Plastic / Metal
Delivery Method:	EMS/DHL/UPS/TNT/FEDEX
MTBF:	More than 100,000hours
Payment Method:	L/C/T/T ,Western Union /MoneyGram
Color:	Block / White
DC Tip:	Oval tip
AC Type:	US/UK/AU/EU/CH etc.
Model Label:	Customize
Certificate:	CCC,FCC,ROHS,UL,GS
Efficiency:	More than 88%

Payment & Shipping Terms:

Minimum Order Quantity:	Negotiation
Price:	Negotiation
Packaging Details:	According to customer’s requirment
Delivery Time:	7-15days
Payment Terms:	L/C T/T,Paypal
Supply Ability:	500,000 Piece/Pieces per Month and more

Contact Now

Detailed Product Description

Highlight:	Computer Switching Power Supply

1:Product name :5v regulated power supply
2:Input :100v ~240v
3:Output : 5w~120w
4:Material :Plastic

5v regulated power supply 12W UK Plug DC Adapter CE, C /UL, GS, FCC and CCC Marks

Model: winwell-12G-12 FUK
Max output wattage: 12W
AC input voltage: 100V-240V (90-264Vac max)
AC frequency: 47-63Hz
DC output: 12V (output regulation 11.3V-14.5V)
DC output: 0 to 1A max
No load power consumption: <;;0.3W
Efficiency: 78% minimum
Ripple and noise: 400MVP-p
Working temperature: 0-40 degrees Max
Leakage current: <;;0.25mA
Short circuit protection
Over current protection
Over voltage protection
Open circuit protection

Humidity:
Operating humidity: 20 to 85% RH
Storage humidity: 5 to 95% RH
Hi-pot test:
Hi-pot: 3, 000V AC (primary-secondary)
MTBF (mean time between failures): 50, 000 hours at 25 degrees Centigrade
Dimensions: 70 x 49.2 x 72.7mm (L x W x H) maximum
Safety: TUV- BS, CE
Safety standard: EN 60950-1
Meet CEC: Level V

5v regulated power supply 12W UK Plug DC Adapter CE, C /UL, GS, FCC and CCC Marks
